TUNNEL LED
Luminaire for lighting road tunnels, underpasses, and industrial spaces such as halls, warehouses, workshops, and filling stations with a high concentration of aggressive chemicals and dust.
Technical description:
The luminaire body and frame are made of chemically highly resistant polished stainless steel sheet. A 5 mm thick tempered protective glass is bonded into the frame.
High dust tightness and resistance to the ingress of unwanted moisture are ensured by an airtight connection between the frame and the housing, using a silicone gasket seated in a groove of the body. The frame is firmly attached to the housing with four stainless steel clips. Two of the clips allow the frame to hang freely below the housing during installation.
The reflector is made of chemically polished aluminum sheet. The luminaire is equipped with two plastic cable glands.
You can find the luminous intensity plots in the gallery
Made in EU
Made in EU
Version
LED
Version
Voltage
Temperature
Control
Degree of protection (IP)
Installation
Emergency version
Technical description
Luminaire body
Diffuser
Surface finish
Max. cable cross-section
Cable glands (material)
Cable glands (ø)
Lifetime
Lifetime
120.000 hours, L90B10
Use
| Type | Power [W] / Luminous flux [lm] | Light output [lm/W] | Number of LED PCBs | Angle of beam [°] | Color temperature [K] | CRI | Weight [kg] |
|---|---|---|---|---|---|---|---|
| 691 04 01 | 300 / 39 379 | 132 | 18x | 120 / 60 / Asymmetric | 4000, 5000, 5700, 6500 | >80 | 21 |
| 691 04 02 | 250 / 34 299 | 136 | 18x | 120 / 60 / Asymmetric | 4000, 5000, 5700, 6500 | >80 | 21 |
| 691 04 03 | 200 / 27 368 | 136 | 18x | 120 / 60 / Asymmetric | 4000, 5000, 5700, 6500 | >80 | 21 |
| 691 04 04 | 150 / 21 595 | 141 | 18x | 120 / 60 / Asymmetric | 4000, 5000, 5700, 6500 | >80 | 21 |
Maximum breaker load and number of luminaires connected in series:
| Circuit breaker | C10 | C13 | C16 | C20 | B10 | B13 | B16 | B20 |
|---|---|---|---|---|---|---|---|---|
| Number of luminaires | 2 | 3 | 4 | 5 | 2 | 2 | 3 | 4 |
| Cross section of the conductor | 1,5 | 1,5 | 2,5 | 4 | 1,5 | 1,5 | 2,5 | 4 |
| Start-up current lmax | Time |
|---|---|
| 80A | 250us |
| *Actual values may vary due to the types of circuit breakers used and the installation environment. | |
